TCMMRC FPV Frame Kit Carbon Fiber Beast of prey 225 225mm 5 Inch 5mm Arm With 3D Printed Parts for RC FPV Racing Drone
TCMMRC FPV Frame Kit Carbon Fiber Beast of prey 225 225mm 5 Inch 5mm Arm With 3D Printed Parts for RC FPV Racing Drone
Out of stock
Share this product
★The frame structure of the split type outdoor flower flying crossing machine adopts the classic hybrid-x layout structure design.
★Enough and applicable fuselage space design, side plate provides mounting hole for 28mm (runcam / foxker general) camera
★The upper part and the lower part are connected by the front and the back six print pieces, and the print piece is the shell;
The printout can also provide the buffer force of fuselage impact for the flexible material;
★Hybrid-x fuselage design, stable structure, suitable for outdoor fancy flight.
Material: 3K carbon fiber matte
Wheelbase: 225 mm
Motor hole position: M3*16*19mm
Flight control hole position: M3*20*20/30.5*30.5mm (supports 2 kinds of holes)
Camera hole position: M2*28*28mm（Runcam/FOXXER）
Paddle: 5 inches
Base plate*1
Arm*4
Tail fixed wing*1
Middle plate*1
Side plate*2
Connecting 3D print*6
Shell 3D print*1
Iron screw package：M3*8=6，M3*6=16，M3*12=4,M3 locks silver nuts=8.
Aluminum column package：M3*29=2（black mesh）M3*5=2个（Bright black） M3*20=3（Bright black）
