RunCam Phoenix Oscar Edition 2.5mm (M12) FOV140°
RunCam Phoenix Oscar Edition 2.5mm (M12) FOV140°
Regular price
Rs. 3,801.58
Sale price
Rs. 3,801.58
Regular price
Tax included.
Shipping calculated at checkout.
Out of stock
Share this product
SKU: A02882
Super 1000TVL Clear Image
Super 120dB WDR
https://oscarliang.com/runcam-phoenix-fpv-camera-oscar-edition/
Super 120dB WDR
- Joystick Control & UART Control Switchable
- The top left corner of the screen will shortly display the current control mode.
The default is Joystick control mode.
- Short the two camera control pins
- Then power on, camera will auto switch between the two modes
-
- The mode can be saved after power off. After switching to the desired mode, please unplug the short-circuit cable.
- UART Control works with Flight Controllers:
- BetaFlight 3.3 or above / ButterFlight 3.4 or above / CleanFlight 2.2 or above / Kiss Flight RC36 or above
Dimensions
Package
-
Camera*1 -
1928 ABS bracket*1
6pin FPV silicone cable*1 -
Set of screws*1
Manual*1
Parameters
| Model | RunCam Phoenix Oscar Edition | ||
| Image Sensor | 1/3" 120dB WDR Sensor | ||
| Horizontal Resolution | 1000TVL | ||
| Lens | 2.5mm (M12) FOV140° (4:3) / 1.8mm (M12) FOV160° (16:9) | ||
| Signal System | 4:3 / 16:9 switchable | ||
| Mirror/Flip | Available | ||
| Signal System | PAL / NTSC Switchable | ||
| Integrated OSD | Yes | ||
| S/N Ratio | >50dB (AGC OFF) | ||
| Electronic Shutter Speed | Auto | ||
| Auto Gain Control (AGC) | Auto | ||
| Min. Illumination | 0.01Lux@1.2F | ||
| WDR | D-WDR | ||
| Day/Night | Color/Auto/B&W | ||
| Menu Control | Cable Control / Remote Control Switchable | ||
| Power | DC 5-36V | ||
| Current |
|
||
| Housing Material | ABS | ||
| Net Weight | 9g | ||
| Dimensions | 19mm*19mm*20mm |
Download
Manual
