SPECIFICATIONS

• 1103 8000kv (3s 12a+ esc required)
• 4.8 grams each (Including plug w/ 50mm wire)
• 3 pin 1.25mm pitch picoblade connector (works with 26x26 brushless whoop FC’s/ or cutoff and direct solder)
• 50mm long silicone wire
• 1.5mm diameter, 4mm tall shaft with 2x M2 screw holes for prop mounting (will work with press on props, but we don’t recommend it)
• 9mm M2 bolt pattern (6mm bolts included with kit)
• Prop screws included (Please check screw to stator clearance before installing props)

SUGGESTED PROPELLERS:

• HQ T2x2.5x3
• HQ T2.5x3.5x3
• HQ T3x3 (2s only)
• Lumenier 2.2x3
• 65mm props
