Wires & Connectors
Input Wires : Red-14AWG-100mm/ Black-14AWG-100mm
Output Wires : No wires but solder tabs
Input Connectors : XT60(w/ Wires Soldered on)
Output Connectors : No

Size & Weight
Size : 40x33x5mm
Weight : 12g

Features
Firmware : Hobbywing_XRotor_BLHeli_32_AT421 Firmware
ESC Programming : Supported
Programming Tool : BLheliSuite32
DEO : Supported
Throttle Range Calibratioon : Supported
Oneshot125 Mode : Supported
Oneshot42 Mode : Supported
MultiShot Mode : Supported
DShot150/300/600/1200 : Supported
Timing : Supported
Motor Rotation : Supported

Applications: 130-300mm FPVs
