SPECIFICATION

• Chipset - ublox UBX-M8030
• Flash memory for saving configuration.
• Frequency - L1, 1575.42MHz ; L2,1561.10MHZ；L3,1602.00MHZ
• Baud Rate - 4800bps-921600bps (Default - 9600bps)
• Channel - 72ch
• Sensitivity - (Tracking: -164dBm) | (Capture: -159dBm) | (Cold Start - 147dBm)
• Cold start - Average 26 seconds
• Warm start - Average 24 seconds
• Hot start - Average 1 second
• Accuracy - (HorizontalPosition:Autonomous<2m average) | (SBAS < 2.0m average) | (Timepulse signal: RMS 30 ns)
• Maximum height - 50000m
• Maximum speed - 500 m/s
• Maximum acceleration - ≦ 4G
• Refresh Rate - 1-10 Hz
• Size - 20 x 22 x 6 mm
• Weight - 5.2g
• Input Voltage - 3.3V-5V
